WMW GOTHA UBR 10 x 2000 /1-16 | 1982/2024

Sheet width 2000 mm
Sheet thickness - max. 10 mm
Sheet thickness - min. 3 mm
Number of straightening rollers 13 Rollers
Straightening roller diameter 145 mm
Standard speed 16 m/min
Bale length 2330 mm
Centre distance of the straightening rollers 150 mm
Support roller diameter 290 mm
Main drive motor 30 kW
Weight 32 tonnes
Blechbreite 2000 mm
Blechdicke – max. 10 mm
Blechdicke – min. 3 mm
Anzahl Richtwalzen 13 Rollers
Richtwalzendurchmesser 145 mm
Richtgeschwindigkeit 16 m/min
Ballenlänge 2330 mm
Mittenabstand der Richtwalzen 150 mm
Stützwalzendurchmesser 290 mm
Hauptantriebsmotor 30 kW
Gewicht 32 t
Zusatzinformationen
- Number of support rollers: 21/24
- Number of supports (top/bottom): 3 /3
- Lifting speed of the traverse: 0.71 mm /sec
- Lifting range of the traverse: -18 mm to +42 mm
- Max. swivelling of lower crossbar: 8 mm
